Hollyland Astra P1 Overview

Capture crisp and vibrant 4K images during live events with the Astra P1 UHD 4K PTZ Camera from Hollyland.
Equipped with a built-in 1/1.8" high-quality 8.42MP CMOS sensor and HDMI and 3G-SDI connectivity for flexible compatibility, the Astra P1 is ideal for houses of worship and other presentation halls.
It offers 30x optical and 16x digital zoom, supports AI auto-tracking, intelligent face detection AE, and NDI HX3, and boasts capture resolutions up to UHD 4K at 60 fps. You can store up to 255 positions with an accuracy of 0.1°.

Hollyland Astra P1 UHD 4K PTZ Camera with 30x Optical Zoom

Name: Hollyland Astra P1 UHD 4K PTZ Camera with 30x Optical Zoom
SKU: ASTRA P1
Price: 8499 MYR
Availability: InStock

SKU: ASTRA P1

RM 8,499.00

Quantity

Hollyland Astra P1 Specs

Key Specs

Image Sensor	1/1.8"-Type
Effective Sensor Resolution	8.42 Megapixel
Shutter Speed	1/10000 to 1/30 Second
Max Optical Zoom	30x
Max Digital Zoom	16x
Max Video Output	via HDMI Up to UHD 4K at 25/29.97/30.00/50/59.94/60.00 fps via SDI/BNC Up to 1080p at 25/29.97/30.00/50/59.94/60.00 fps Show More
Max Recording Modes	No
Broadcast Output	NTSC/PAL
Supported Protocols	Video Streaming DHCP/HTTP/NDI\|HX3/RTMP/RTMPS/RTSP/SRT/TCP
IP Streaming	320 x 240 to 3840 x 2160
Wireless	No
PoE Support	Yes: PoE+ 802.3at
Mounting	1x Proprietary for Ceiling 1x Proprietary for Wall

Imaging

Image Sensor	1/1.8"-Type CMOS
Effective Sensor Resolution	8.42 Megapixel
IR Cut Filter	No

Exposure Control

Lens

Video Capture

Video Output	via HDMI 3840 x 2160 at 25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080p at 29.97/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 59.94/60.00 fps via SDI/BNC 1920 x 1080 at 25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 59.94/60.00 fps
Embedded Audio	HDMI/SDI
Internal Recording	No
Broadcast Output	NTSC/PAL
Supported Protocols	Video Streaming DHCP/HTTP/NDI\|HX3/RTMP/RTMPS/RTSP/SRT/TCP
IP Streaming	320 x 240 to 3840 x 2160

Control

Presets	255
Pan/Tilt	Pan: 170° Tilt: 120° (30 to 90°)

Networking

Wireless

Interface

Video I/O	1x HDMI 2.0 Output 1x BNC (3G-SDI) Output
Audio I/O	1x 1/8" / 3.5 mm TRS Stereo Line Input 1x 1/8" / 3.5 mm TRS Stereo Line Output
Other I/O	1x Block 2-Pin (RS-485) 1x Mini-DIN 8-Pin (RS-232) 1x RJ45 (Ethernet) 1x USB-A (USB 2.0) 1x USB-B (USB 3.0)
Built-In Microphone	No
Built-In Speaker	No

Power

Environmental

General

Mounting	1x Proprietary for Ceiling 1x Proprietary for Wall
Dimensions (W x H x D)	7.4 x 8.9 x 6.7" / 188 x 226 x 169 mm
Weight	5.1 lb / 2.3 kg (Body Only)

key features
