Power Consumption
45W
Power Supply
USB Type-C
USB Rated Output
USB-A:5V/1A
Battery Capacity
6800mAh
Monitor Screen Size
8inch LCD Resolution: 1200*1920; Brightness: 650nits;
Contrast ratio(1500:1), Viewing Angle (full viewing Angle), NTSC 80%
Local Video Inputs
HDMI,USB-A
Video Over Ethernet
RTMP/RTMPS/SRT
Video Input Connectors
HDMI,USB-A,RJ-45,USB Type-C
Video Input Aspect Ratios
16:9; 4:3; 1:1
Video Input Deinterlacing
No
Live Broadcast Video input Resolution
480p/720p/1080p(up to 60fps)/4k 30fps
Video Encoded Format
H.264 H.265
Video processing Bitrate control
CQ, VBR, CBR
Hardware-Accelerated Video Encoding
Optional
Video Output Signal Types
FLV-RTMP,HDMI,UVC
Video Output Connectors
HDMI OUT, USB-C
Video Output Streaming protocols
RTMP, RTMPS, MJPEG, SRT
Live Broadcast Video Output Resolution
480p/720p/1080p(up to 60fps)/4k 30fps
Analog Audio Input Connectors
Line In, Mic In, 3.5mm
Digital Audio Inputs
USB, HDMI, RTMP(From internet), Local video(From SD card)
Digital Audio Input Connectors
USB-A, HDMI, USB-C
Audio Input Mute
Yes
Audio Input Format
32KHZ/44.1KHZ/48KHZ :16bit
Audio Encoded Format
(AAC)44.1K/48KHZ 2Ch 16bit
Analog Audio Output
3.5mm headphone jack
Digital Audio Outputs
HDMI audio (Embedded), USB Audio (Embedded)
Record Formats
MP4
Wi-Fi
2.4G/ 5G๏ผSupport WiFi6๏ผ
4G Network
4G Network Countries & Frequency Band For
Users: [Variant for North America๏ผUS/Canada/Mexico)]
B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B66/B71
Notes: Mexico B4 For Non-US/Canada/Mexico
Users: (EU: Variant for EMEA/India/Korea/Taiwan/South Asia/Latin/America/Australia/New Zealand)
Users: B1/B3/B7/(B8) Notes: Thailand B1/B3
Please note that the certification of Yolobox Mini is in line with the mainstream open 4G band requirements of operators in this country or region. For details, please refer to the approval report of this country or region.
USB Communication Standard
USB 2.0 and USB 3.0
Ethernet Data Rate
10/100/1000M, half/full duplex with autodetect
SIM Card Size
Nano-SIM Card
SDCard format
FAT32(Under 128G), NTFS, EX-FAT
Operating Temperature
0โ-40โ
Operating Humidity
15%-85%, No Condensation
Country of Origin
Made in China
